GIGABYTE MB B760 LGA1700 4 x DDR5 3 x M.2 4 x SATA 1 x DisplayPort 1 x HDMI port ATX, B760 GAMING X AX

Antenna: 2
, Audio Integrated: yes
, Audio Interface: 6 (3.5-mm minijack)
, Audio Output Mode: 7.1 Channel Surround
, BIOS Features: Gigabyte Q-Flash WfM 2.0 Support PnP 1.0a Support UEFI SMBIOS 2.7 Support DMI 2.7 Support ACPI 5.0 Support 256 Mb Flash ROM
, BIOS Type: AMI
, Bluetooth: Bluetooth 5.2
, Box Weight Brutto (kg): 1.65 kg
, Chipset: Intel B760
, Compliant Audio Standards: High Definition Audio
, CPU Maximum Quantity Supports: 1
, CPU podnožje: Socket 1700
, Data Link Protocol Supports: 1 Gbps 2.5 Gbps
, Device Location: Integrated
, DisplayPort: 1
, Form Factor: ATX
, Hardware Monitoring: CPU Temperature CPU Voltage System Temperature System Voltage
, HDMI: 1 (HDMI (Type A))
, Height (mm): 244 mm
, Integrated: Storage Controller:PCI Express 4.0 x4 (3 x M.2 (Key M))Storage Controller:Supports: Level 0, Level 1, Level 10, Level 5SATA III-600 (4)
, LAN Integrated: yes
, LAN: 1 (RJ-45)
, Mainboard Features: Fan Speed Control
, Maximum Installable System Memory Storage Capacity: 192 GB
, Memory Features: Unbuffered Dual Rank Single Rank XMP
, Memory Form Factor: DIMM 288-pin
, Memory Slot Total Quantity: 4
, Memory Speed: 4800MHz(PC5-38400)
, Pack Weight Brutto (kg): 1.65 kg
, Pack Weight Netto (kg): 1.65 kg
, Package Type: Retail
, Packs in Box: 1
, PCI Express 3.0 x16: 2
, PCI Express 4.0 x16: 1
, Pieces in pack: 1
, Plug-in-card: Wi-Fi Controller:AMD Wi-Fi 6E RZ608
, Power Connectors Type: 24+8 pin
, Provides Error Checking Method: non-ECC
, Retail Packaging Net Weight Carton: 0.01 kg
, Retail Packaging Net Weight Plastic: 0.01 kg
, Software Included: Norton Internet Security (OEM version)
, Supported Operating System: Microsoft Windows 10 64-bit Microsoft Windows 11 64-bit
, Supports Central Processor Unit: Intel 12th Gen Processors Intel 13th Gen Processors
, USB 2.0: 5 (USB 2.0 (type A))
, USB 3.2 Gen 1: 1 (USB 3.2 (type C)); 1 (USB 3.2 (type A))
, USB 3.2 Gen 2: 1 (USB 3.2 (type A))
, Video Chipset: Intel HD Graphics
, Video Controller Integrated: yes
, Vrsta memorije: DDR5 SDRAM
, Warranty Products Returnable: Yes
, Warranty Term (month): 36 month(s)
, Warranty validation Criteria: Serial Number
, Width (mm): 305 mm
, Wi-Fi: IEEE 802.11ax Wi-Fi 6
