- High-Speed Wi-Fi - 300 Mbps wireless transmission rate is ideal for both bandwidth sensitive tasks and basic work
- Boosted Coverage - Two omnidirectional antennas and 2×2 MIMO deliver strong Wi-Fi signal and reliable connections
- Multi-Mode 4 in 1 - Supports Router, Access Point, Range Extender, and WISP modes to meet any network need
- Parental Controls - Manages when and how connected devices can access the internet
- Guest Network - Provides separate access for guests while securing the host network
- Smooth HD Streaming - Supports IGMP Proxy/Snooping, Bridge and Tag VLAN to optimize IPTV streaming
- IPv6 Supported - Compatible with the IPv6 (the latest Internet Protocol version 6)
Specifications
WIRELESS
- Standards: Wi-Fi 4 (IEEE 802.11n/b/g 2.4 GHz)
- WiFi Speeds: N300 (2.4 GHz: 300 Mbps (802.11n))
- WiFi Range: 2 Bedroom Houses (2× Fixed Antennas)
- WiFi Capacity: Legacy
- Working Modes: Router Mode, Access Point Mode, Range Extender Mode, WISP Mode
HARDWARE
- Processor: Single-Core CPU
- Ethernet Ports:
1× 10/100 Mbps WAN Port
4× 10/100 Mbps LAN Ports
- Buttons: Reset Button
- Power: 5V = 0.6A
SECURITY
- WiFi Encryption: WEP, WPA, WPA2, WPA/WPA2-Enterprise (802.1x)
- Network Security: SPI Firewall, Access Control, IP & MAC Binding, Application Layer Gateway
- Guest Network: 1× 2.4 GHz Guest Network
SOFTWARE
- Protocols: IPv4, IPv6
- Parental Controls: URL Filtering, Time Controls
- WAN Types: Dynamic IP, Static IP, PPPoE, PPTP, L2TP
- Quality of Service: QoS by Device
- NAT Forwarding: Port Forwarding, Port Triggering, DMZ, UPnP
- IPTV: IGMP Proxy, IGMP Snooping, Bridge, Tag VLAN
- DHCP: Address Reservation, DHCP Client List, Server
- DDNS: NO-IP, DynDNS
- Management: Tether App, Webpage
PHYSICAL
- Dimensions (W×D×H): 115×106.7×24.3 mm
- Package Contents: Wi-Fi Router TL-WR844N, Power Adapter, RJ45 Ethernet Cable, Quick Installation Guide
OTHER
- System Requirements:
* Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser
* Cable or DSL Modem (if needed)
* Subscription with an internet service provider (for internet access)
- Certifications: FCC, CE, RoHS
- Environment:
* Operating Temperature: 0C to 40C (32F to 104F)
* Storage Temperature: -40C to 70C (-40F to 158F)
* Operating Humidity: 10% - 90% non-condensing
* Storage Humidity: 5% - 90% non-condensing
TEST DATA
- WiFi Transmission Power:
* CE: <20dBm(2.4GHz)
* FCC: <30dBm
- WiFi Reception Sensitivity:
* 270M: -70dBm@10% PER
* 130M: -74dBm@10% PER
* 108M: -74dBm@10% PER
* 54M: -77dBm@10% PER
* 11M: -87dBm@8% PER
* 6M: -90dBm@10% PER
* 1M: -98dBm@8% PER
