Key Features
RJ45 INTERFACE
- 6× 10/100/1000Mbps Gigabit Ethernet ports
- 4× ports support 54V DC power to PoE powered device
POWER OVER ETHERNET
- Complies with IEEE 802.3af/at Power over Ethernet end-span PSE
- Up to 4 IEEE 802.3af/at devices powered
- Supports PoE power up to 30 watts for each PoE port
- 55-watt PoE budget
- Auto detects powered device (PD)
- Circuit protection prevents power interference between ports
- Remote power feeding up to 100m
SWITCHING
- Hardware based 10/100/1000Mbps auto-negotiation and auto MDI/MDI-X
- Flow control for full duplex operation and back pressure for half duplex operation
- 9216 bytes jumbo packet size support
- Integrates address look-up engine, supporting 8K absolute MAC addresses
- Automatic address learning and address aging
- Supports port-based VLAN and loop protection
HARDWARE
- LED indicators for PoE ready and LINK/ACT
- One 55V DC power jack
Specifications
HARDWARE SPECIFICATIONS
- Network Connector: 6-port RJ45 for 10/100/1000BASE-T, auto MDI / MDIX
- PoE Inject Port: 4-port with 802.3af/at PoE injector function (port 1 to port 4)
- LED Display:
* System: Power (Green)
* Per PoE port: PoE (Orange, port 1 to port 4), PoE max. (Orange)
* Ethernet port: 1000 LNK (Green), 10/100 LNK (Orange)
- Thermal Fan: Fanless design
- Switch Architecture: Store and Forward switch architecture
- MAC Address Table: 8K MAC address table with auto learning function
- Switch Fabric: 12Gbps
- Switch Throughput: 8.92Mpps @64 bytes
- Jumbo Packet: 9216 bytes
- Flow Control:
* Back pressure for half-duplex
* IEEE 802.3x pause frame for full-duplex
- Power Requirements: 55V DC, 1.1A
- ESD Protection: 6kV DC
- Power Consumption: Max. 60 watts, 204.6 BTU
- Dimensions (W×D×H): 160×92.5×28 mm
- Weight: 374 g
POWER OVER ETHERNET
- PoE Standard:
* IEEE 802.3af Power over Ethernet/PSE
* IEEE 802.3at Power over Ethernet Plus/PSE
- PoE Power Supply Type: End-span
- Power Pin Assignment: 1/2(+), 3/6(-)
- PoE Power Output:
* Per port 54V DC, 300mA. max. 15.4 watts (IEEE 802.3af)
* Per port 54V DC, 600mA. max. 30 watts (IEEE 802.3at)
- PoE Power Budget: 55 watts
STANDARD CONFORMANCE
- EMI Safety: FCC Class B, CE
- Standard Compliance:
* IEEE 802.3 Ethernet
* IEEE 802.3u Fast Ethernet
* IEEE 802.3ab Gigabit Ethernet
* IEEE 802.3x Flow Control
* IEEE 802.3af Power over Ethernet
* IEEE 802.3at Power over Ethernet Plus
ENVIRONMENT
- Operating Environment: 0 to 50 degrees C
- Storage Environment: -10 to 70 degrees C
- Operating Humidity: 5% - 95%, relative humidity, non-condensing
- Storage Humidity: 5% - 95%, relative humidity, non-condensing
