- With its Full HD (1920×1080) resolution and accurate Projective Capacitive 10 point touch technology, the ProLite T2454MSC-B1AG delivers seamless and accurate touch response
- Featuring IPS LCD screen technology, it offers exceptional colour performance and wide viewing angels, making it a perfect choice for a vast array of interactive applications
- The Anti Glare coating helps to avoid issues with reflections and external light sources affecting colour reproduction, contrast and sharpness
- Its flexible stand can be positioned at several angles creating a comfortable and ergonomic user experience
- The ProLite T2454MSC-B1AG is the ideal solution for interactive signage, instore retail, POS and interactive presentations
TOUCH TECHNOLOGY - CAPACITIVE
- This technology uses a sensor-grid of micro-fine wires integrated into the glass that covers the screen
- Touch is detected because electrical characteristics of the sensor grid change when human finger is placed on the glass
- Thanks to the glass overlay this technology is highly durable, and the touch function remains unaffected even if the glass is scratched
- It offers perfect picture performance and will work with human finger (also latex gloved) and stylus-pen
IPS
- IPS displays are best known for wide viewing angles and natural, highly accurate colours
- They are especially suited for colour-critical applications
AG COATING
- The anti-glare coating is used in professional-grade displays to help avoid issues with reflections and external light sources affecting colour reproduction, contrast and sharpness
- It also makes the screen less susceptible to dust, grease and dirt marks
SPEAKERS
- This LED monitor is equipped with two high quality stereo speakers
VESA
- VESA mount compliance means you can easily mount the display to any mounting that complies with the VESA standard
Specifications
DISPLAY CHARACTERISTICS
- Design: Ultra thin bezel
- Diagonal: 23.8" (60.5cm)
- Panel: IPS LED, AG coated glass
- Native resolution: 1920×1080 @60Hz (2.1 megapixel Full HD)
- Aspect ratio: 16:9
- Panel brightness: 250 cd/m2
- Static contrast: 1000:1
- Advanced contrast: 5M:1
- Response time (GTG): 4ms
- Viewing zone: 178(H)/178(V), Right/Left: 89/89, Up/Down: 89/89
- Colour support: 16.7mln 8bit
- Horizontal Sync: 30 - 80kHz
- Viewable area (W×H): 527.04×296.46 mm
- Pixel pitch: 0.274 mm
- Bezel colour and finish: Black, matte
TOUCH
- Touch technology: Projective capacitive
- Touch points: 10 (HID, only with supported OS)
- Touch method: stylus, finger, glove (latex)
- Touch interface: USB
- Supported operating systems: All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section.
- Palm rejection: Yes
INTERFACES / CONNECTORS / CONTROLS
- Analog signal input: 1× VGA
- Digital signal input: 1× HDMI
- Audio output: Speakers 2× 2W
- HDCP: Yes
- USB HUB: ×2 (v.3.0)
FEATURES
- OSD key lock: Yes
GENERAL
- Control buttons: Auto, + Up, - Down, Menu, Power
- User controls: Picture adjust (brightness, contrast, Eco, i-Style Color, adv. contrast), Geometry (pixel clock, phase, horizontal position, vertical position, aspect), Color settings (gamma, color temp), OSD (OSD horizontal position, OSD vertical position, OSD time, language, auto power off, touch wake up), Extra (reset, signal select, audio input, opening logo, LED, Overdrive, Information, volume, auto adjust)
- Convenience: Kensington-lock prepared
- Blue light reducer: Yes
- Plug&Play: DDC2B
MECHANICAL
- Height adjustment: 268 mm
- Tilt angle: 5 Up - 90 Down
- VESA mounting: 100×100 mm
- MTBF: 30.000 hours (excluding backlight)
ACCESSORIES INCLUDED
- Cables: Power (1.8m), VGA (1.8m), USB (1.8m), HDMI (1.8m)
- Guides: Quick start guide, safety guide
POWER MANAGEMENT
- Power supply unit: Internal
- Power supply: AC 100 - 240V, 50/60Hz
- Power usage: 23.7W typical, 0.46W stand by, 0.29W off mode
SUSTAINABILITY
- Regulations: CB, CE, TUV-Bauart, EAC, VCCI-B, RoHS support, ErP, WEEE, EPEAT, REACH
- Energy efficiency class (Regulation (EU) 2017/1369): F
- REACH SVHC: Above 0.1%: Lead
DIMENSIONS / WEIGHT
- Product dimensions (W×H×D): 540.5×388×128 mm
- Weight: 5.5 kg
