Audio Chipset: Realtek ALC1220-VB
, Audio Integrated: yes
, Audio Interface: 2 (3.5-mm minijack)
, Audio Output Mode: 7.1 Channel Surround
, BIOS Features: Gigabyte Q-Flash Gigabyte Xpress Install WfM 2.0 Support PnP 1.0a Support UEFI SMBIOS 2.7 Support DMI 2.7 Support ACPI 5.0 Support 256 Mb Flash ROM
, BIOS Type: AMI
, Box Weight Brutto (kg): 1 kg
, Chipset: Intel Z690
, Compliant Audio Standards: High Definition Audio DSD (Direct Stream Digital)
, CPU Maximum Quantity Supports: 1
, CPU podnožje: Socket 1700
, Data Link Protocol Supports: 2.5 Gbps
, Device Location: Integrated
, DisplayPort: 1
, EAN Code: 4719331827632
, Form Factor: ATX
, Hardware Monitoring: Chassis Fan Tachometer System Temperature System Voltage
, HDMI: 1 (HDMI (Type A))
, Height (mm): 244 mm
, Integrated: Storage Controller:Supports: Level 0, Level 1, Level 10, Level 5SATA III-600 (6)Storage Controller:PCI Express 4.0 x4 (2 x M.2 (Key M))Storage Controller:PCIe 4.0 x4/SATA (1 x M.2 (Key M))
, LAN Integrated: yes
, LAN: 1 (RJ-45)
, Mainboard Features: AMD 2-Way CrossFire TechnologyIntel Optane Memory ReadyAMD Quad CrossFireRGB Fusion
, Maximum Installable System Memory Storage Capacity: 128 GB
, Memory Features: Two DDR Channels Unbuffered Dual Rank Single Rank XMP
, Memory Form Factor: DIMM 288-pin
, Memory Slot Total Quantity: 4
, Memory Speed: 2133MHz(PC4-17000) 2400MHz(PC4-19200) 2666MHz(PC4-21300) 2800MHz(PC4-22400) 2933MHz(PC4-23400) 3000MHz(PC4-24000) 3200MHz(PC4-25600)
, Pack Weight Brutto (kg): 1 kg
, Pack Weight Netto (kg): 0.8 kg
, Package Type: Retail
, Packs in Box: 1
, PCI Express 3.0 x16: 2
, PCI Express 5.0 x16: 1
, Pieces in pack: 1
, Power Connectors Type: 24+8+4 pin
, Provides Error Checking Method: non-ECC
, Retail Packaging Net Weight Carton: 0.1 kg
, Retail Packaging Net Weight Plastic: 0.1 kg
, S/PDIF-out Optical: 1 (TOSLINK)
, Software Included: Norton Internet Security
, Supported Operating System: Microsoft Windows 10 64-bit Microsoft Windows 11 64-bit
, Supports Central Processor Unit: Intel 12th Gen Processors
, USB 2.0: 4 (USB 2.0 (type A))
, USB 3.2 Gen 1: 3 (USB 3.2 (type A))
, USB 3.2 Gen 2 x2: 1 (USB 3.2 (type C))
, USB 3.2 Gen 2: 2 (USB 3.2 (type A))
, Vrsta memorije: DDR4 SDRAM
, Warranty Products Returnable: Yes
, Warranty Term (month): 36 month(s)
, Warranty validation Criteria: Serial Number
, Width (mm): 305 mm
