ASUS TUF GAMING B760-PLUS WIFI LGA1700 ATX gaming MB - Intel B760 4xDIMM DDR5 3xM.2 4xSATA PCIe 5.0 2.5Gb Ethernet WiFi 6 + Bluetooth 1xDisplayPort 1xHDMI with Aura Sync support

All motherboards by ASUS are designed and tested to meet the highest quality standards. Responsive customer support and frequent BIOS and driver updates ensure that youre getting the fastest, most reliable performance - all the time.
Architecture Features: Intel Turbo Boost Technology 2.0 Intel® Rapid Storage Technology enterprise Intel Turbo Boost Max Technology 3.0
, Audio Data Width: 24-bit
, Audio Integrated: yes
, Audio Interface: 5 (3.5-mm minijack)
, Audio Output Mode: 7.1 Channel Surround
, BIOS Features: ASUS CrashFree BIOS 3 UEFI PXE boot 128 Mb Flash ROM ASUS EZ Flash 3
, BIOS Type: AMI
, Bluetooth: Bluetooth 5.2
, Box Weight Brutto (kg): 9.916 kg
, Cable Included: 2 x SATA 6Gb/s Cables
, Chipset: Intel B760
, Compliant Audio Standards: High Definition Audio
, CPU Maximum Quantity Supports: 1
, CPU Socket Standard: Socket 1700
, Data Link Protocol Supports: 2.5 Gbps
, Device Location: Integrated
, DisplayPort: 1
, EAN Code: 4711387095119
, Form Factor: ATX
, HDMI: 1 (HDMI (Type A))
, Height (mm): 244 mm
, Included Accessories: Antenna Stickers User Guide
, Integrated: Storage Controller:Supports: Level 0, Level 1, Level 10, Level 5SATA III-600 (4)Storage Controller:PCI Express 4.0 x4 (3 x M.2 (Key M))Wi-Fi Controller:1 x M.2 (Key E)
, LAN Integrated: yes
, LAN: 1 (RJ-45)
, Mainboard Features: RGB LED
, Maximum Installable System Memory Storage Capacity: 192 GB
, Memory Features: Two DDR Channels Unbuffered XMP OptiMem II
, Memory Form Factor: DIMM 288-pin
, Memory Slot Total Quantity: 4
, Memory Speed: 7200MHz
, Memory Type: DDR5 SDRAM
, Packs in Box: 5
, PCI Express 3.0 x1: 2
, PCI Express 3.0 x16: 1
, PCI Express 5.0 x16: 1
, Provides Error Checking Method: Non-ECC
, S/PDIF-out Optical: 1 (TOSLINK)
, Supported Operating System: Microsoft Windows 10 64-bit Microsoft Windows 11 64-bit
, Supports Central Processor Unit: Intel 12th Gen Processors Intel 13th Gen Processors
, USB 2.0: 1 (USB 2.0 (type A))
, USB 3.2 Gen 1: 3 (USB 3.2 (type A))
, USB 3.2 Gen 2 x2: 1 (USB 3.2 (type C))
, USB 3.2 Gen 2: 1 (USB 3.2 (type A))
, Warranty Products Returnable: Yes
, Warranty Term (month): 36 month(s)
, Warranty Validation Criteria: Serial Number
, Width (mm): 305 mm
, Wi-Fi: IEEE 802.11ac Wi-Fi 5IEEE 802.11ax Wi-Fi 6IEEE 802.11abgn Wi-Fi 4
, WLAN: M.2
